Gigabyte G494-ZB4-AAP2 HPC/AI Server – AMD EPYC™ 9005/9004 – 4U DP 8 x PCIe Gen5 GPUs
- Supports up to 8 x Dual slot Gen5 GPUs
- Conditionally supports
– 8 x NVIDIA H200 NVL PCIe GPUs with 4-way NVLink bridges
– 8 x NVIDIA RTX PRO™ 6000 Blackwell Server Edition GPUs - Dual AMD EPYC™ 9005/9004 Series Processors
- 12-Channel DDR5 RDIMM, 48 x DIMMs
- 2 x 1 Gb/s LAN ports via Intel® I350-AM2
- 12 x 2.5″ Gen5 NVMe/SATA/SAS-4 hot-swap bays
- 2 x M.2 PCIe Gen3 x4
- 8 x FHFL PCIe Gen5 x16 for GPUs
- 2 x FHHL PCIe Gen5 x16
- 1 x FHHL PCIe Gen5 x16 on the front side
- 3 x LP PCIe Gen5 x16
- Quad 3000 W 80 PLUS Titanium redundant power supply
Ordering Numbers: 6NG494ZB4DR000ACP2*
0 ر.س
Description
New AMD EPYC™ Family of Processors – Same Great SP5 Platform
The SP5 socket has reached its pinnacle form with 5th Generation AMD EPYC™ processors. The same successful platform that was shared by AMD EPYC™ 9004 & 8004 series processors is now the same one for AMD EPYC™ 9005 series processors. With up to 192 cores, increased frequencies and cache, this top tier performance platform targets general purpose, cloud native, and technical computing. Building on the advantages of the EPYC™ 9004 series, the new EPYC™ 9005 series adopts the 3nm process with AMD “Zen5” and “Zen5c” core architecture, excelling in both energy efficiency and cost optimization. GIGABYTE has already prepared for this new processor with new servers and updates to existing products for 4th Gen AMD EPYC™ processors.
5th Generation AMD EPYC™ Processors for SP5 Socket
3nmarchitecture
Increased transistor density alongside a reduction in power consumption
Up to 192CPU cores
Dedicated “Zen 5” & “Zen 5c” cores increase compute density
Up to 512MBL3 cache
An L3 cache increase helps to reduce latency in data-intensive operations
12channels
Memory capacity up to 9TB in a 2 DIMM per channel configuration
Up to 160PCIe lanes
Dual socket configuration adds a significant amount of I/O connectivity
CXL 2.0support
Disaggregated compute architecture possible via Compute Express Link
G494-ZB4-AAP2 Block Diagram
G494-ZB4-AAP2 Product Overview
