PNY NVIDIA RTX 4000 SFF Ada Generation – VCNRTX4000ADALP-PB
The NVIDIA RTX 4000 SFF Ada Generation is a compact, high-performance professional GPU designed for demanding workflows such as AI, rendering, simulation, and 3D design. Built on the Ada Lovelace architecture, it delivers powerful performance in a small form factor with low power consumption.
Key Features
- NVIDIA Ada Lovelace Architecture
- 20GB GDDR6 memory with ECC
- 6,144 CUDA cores
- 192 4th Gen Tensor Cores
- 48 3rd Gen RT Cores
- Compact small form factor (SFF) design
- 70W max power consumption (no external power required)
- AV1 encode & decode support
- Supports up to 4 displays (Mini DisplayPort 1.4a)
- VR / AR / XR ready
0 ر.س
Description
The NVIDIA RTX 4000 SFF Ada Generation delivers powerful workstation-class performance in a compact GPU form factor. Powered by the advanced Ada Lovelace architecture, it combines next-generation CUDA cores, ray tracing, and AI acceleration technologies to enable professionals to handle complex workloads efficiently.
With 20GB of GDDR6 ECC memory, this GPU is ideal for handling large datasets, 3D models, and high-resolution rendering tasks. It significantly improves workflows in industries such as architecture, engineering, media production, and AI development.
The inclusion of third-generation RT cores enables faster and more accurate ray tracing, while fourth-generation Tensor cores provide enhanced AI performance for tasks like deep learning, inference, and generative AI.
Its low 70W power consumption and compact dual-slot design make it perfect for small form factor workstations without compromising performance.
Key Features
- NVIDIA Ada Lovelace Architecture
- 20GB GDDR6 memory with ECC
- 6,144 CUDA cores
- 192 4th Gen Tensor Cores
- 48 3rd Gen RT Cores
- Compact small form factor (SFF) design
- 70W max power consumption (no external power required)
- AV1 encode & decode support
- Supports up to 4 displays (Mini DisplayPort 1.4a)
- VR / AR / XR ready
System Requirements
- Intel Core i5 / i7 / i9 / Xeon (or newer)
- PCIe x16 slot
- Compatible workstation chassis
Package Contents
- NVIDIA RTX 4000 SFF Ada Generation GPU
- Full-height bracket (pre-installed)
- Low-profile bracket
- 4× Mini DisplayPort to DisplayPort adapters
Display & Resolution Support
- Up to 4× 5K displays @ 60Hz
- Up to 2× 8K displays @ 60Hz
- HDR support
- 4K HEVC encode/decode
Use Cases
- 3D CAD / CAE
- AI & Deep Learning
- Video editing & rendering
- Simulation & visualization
- Real-time ray tracing
- Edge computing & analytics
| Specification | Details |
|---|---|
| Product | NVIDIA RTX 4000 SFF Ada Generation |
| PNY Part Number | VCNRTX4000ADALP-PB |
| Architecture | NVIDIA Ada Lovelace Architecture |
| Process Size | 4nm NVIDIA Custom Process | TSMC |
| Die Size | 294.5 mm² |
| Transistors | 35.8 Billion |
| CUDA Cores | 6144 |
| Tensor Cores | 192 | Gen 4 |
| RT Cores | 48 | Gen 3 |
| FP32 Performance | 19.2 TFLOPS |
| Tensor Performance | 306.8 TFLOPS |
| RT Core Performance | 44.3 TFLOPS |
| GPU Memory | 20 GB GDDR6 ECC |
| Memory Interface | 160-bit |
| Memory Bandwidth | 320 GB/s |
| Display Connectors | 4 × mDP 1.4a |
| Form Factor | 2.7” H × 6.6” L | Dual Slot |
| Thermal Solution | Active Fansink |
| AR/MR/VR/XR Capable | Yes |
| NVIDIA 3D Vision / Pro | Support via optional 3-pin mini-DIN |
| Frame Lock | Compatible with NVIDIA Quadro Sync II |
| Maximum Power Consumption | 70W (No auxiliary power required) |
| NVENC / NVDEC | 2× / 2× (includes AV1 encode & decode) |
