The Eaton 9E is an online double-conversion power protection at an affordable price with compact yet robust construction. This UPS an ideal choice for industrial, medical and information technology (IT) applications and telecommunications.
0 ر.س
To pick up from our Jeddah or Riyadh office
Free
Courier will deliver to the specified address
Call or email for more information about shipping charges and arrange courier from our team, Thanks
General specifications | Product Name | Eaton 9E UPS |
Catalog Number | 9E15KI | |
UPC | 743172067692 | |
Product Length/Depth | 70.6 cm | |
Product Height | 81.55 cm | |
Product Width | 35 cm | |
Product Weight | 145.22 kg | |
Warranty | 1 year | |
Compliances | CE Marked TUV | |
Certifications | IEC/EN 62040-1 IEC/EN 62040-2 CE EAC | |
Battery | Battery type | Sealed, lead-acid |
Runtime graph | ||
Battery replacement | Replacable batteries | |
Battery quantity | 40 | |
Battery management | Automatic battery testDeep discharge protection | |
Battery rating | 12 V / 7 Ah | |
Extended battery capability | Yes | |
Electrical output | Voltage | 230V |
Wattage | 12 kW | |
Output power factor | 0.8 | |
Output voltage range | 220/230/240 V +/- 2% | |
Output waveform | Sine wave | |
Output nominal voltage | 230V default (220/230/240V) | |
Voltage distortion output (linear load) – max | 3 | |
Feed type | 1 | |
Topology | Online/Double-conversion | |
VA rating | 15 kVA | |
Electrical input | Input connection | Hardwired/fixed connection |
Input nominal voltage | 400V/230V | |
Nominal frequency | 50/60 Hz | |
Input power factor | >.99 | |
Input voltage range | 176-276 V (110-276 V with derating) for 1ph input | |
Input frequency range | 45-66Hz | |
Communications | Includes network card | No |
Communication | USB port (HID compliant)Serial port (RS232)Mini-terminal block for remote power offCommunication slot | |
Ethernet interface | ||
User interface | LCD Display | |
Potential free switch contact | ||
Expansion slots | One slot for optional communication card | |
Software compatibility | Eaton Intelligent Power Manager, Eaton Intelligent Power Protector | |
Type of interface | Other | |
Environmental | Altitude | 3000 m |
Noise level | <55 dB at 1 meter | |
Temperature range | 0° to 40°C (32° to 104°F) | |
Relative humidity | 0-95% non-condensing | |
Additional specifications | Construction type | Free standing model |
Package contents | UPSUSB cableSerial cableUser manual | |
Phase (output) | ||
Internal bypass | ||
Auto shutdown function | ||
Color | Black | |
Efficiency | 93 | |
Rack mounting kit | ||
Phase (input) | 1 or 3 | |
Hot swap power | ||
Compliance information | EU declaration of conformity Eaton 9E UPS | |
Declarations of conformity | EU Declaration of Conformity | |
Manuals and user guides | Eaton 9E UPS – User Manual | |
Eaton 9E UPS – Installation and user manual | ||
Technical data sheets | Eaton 9E UPS – Datasheet |
